From science to solutions: Tackling fouling in industrial filtration systems

Fouling of filters and membranes is a process where unwanted substances accumulate on the surface or within the pores of the filtration media or membranes, which leads to a decrease in their performance.

This phenomenon is particularly significant in filtration systems which are used to treat municipal or industrial wastewater treatment. The fouled media can be sand, garnet or anthracite for multimedia filters or ultrafiltration and reverse osmosis (RO) for membrane based filtration. It is a common issue that reduces efficiency, increases maintenance costs, and can lead to equipment failure.

What are the common factors that lead to fouling?

The causes of fouling can be categorized into four types:

1. Physical fouling

Physical fouling occurs when suspended particles, such as sand, dirt, silt, clay, and other particulate matter, accumulate on the membrane or filter surface. When particles come into contact with the surface, they accumulate on the surface or are trapped in the filtration media pores, forming a cake layer which increases the differential pressure across filtration media resulting in the decreasing of the plant filtration flow rate. These particles settle on surfaces, especially in low-velocity regions, leading to blockages and reduced filtration efficiency.

2. Organic fouling

Organic matter, such as proteins, humic acids, polysaccharides, oils, and greases, along with coagulants from natural water sources or industrial processes, can carry over from the pre-treatment stage and further accumulate on membrane surfaces.

These organic compounds can adsorb onto the membrane surface, leading to the formation of a gel-like layer or a more compact deposit. Over time, the organic layer increases the pressure drop across filtration media and reduces the membrane filtration rate.

3. Biofouling

Biofouling occurs when microorganisms (e.g., bacteria, fungi, algae) attach to the membrane surface and form biofilms. The source of such microorganisms is usually the source water, which can be surface water, industrial waste, or other.

The biofouling is usually enhanced when the water source is carried over from biological unit operations such as aeration, extended aeration or bioreactors. Microorganisms secrete extracellular polymeric substances (EPS) that help them adhere to surfaces. Once attached, biofilms develop and grow, which can clog membrane pores and alter the flow dynamics. Biofouling is particularly problematic in water treatment systems where nutrients and suitable conditions for microbial growth exist.

This type of fouling is common in systems using water from natural sources, or when water remains stagnant for a long time and the disinfection system is absent or inefficient, allowing microbial growth.

4. Chemical fouling (scaling)

This occurs when chemical reactions lead to the formation of undesirable substances or precipitation of dissolved substances like calcium carbonate, silica, barium sulphate etc. that adhere to the membrane.

Chemical reactions in the feed water can result in the formation of compounds that either deposit directly on the membrane or alter the chemical properties of the membrane itself. For example, the presence of strong acids, alkalis, or oxidizing agents can damage or degrade membrane materials.

This type of fouling can occur due to excess doses of chemicals in pre-treatment and are often exacerbated by temperature changes or pH imbalances in the fluid.

How do systems make the most out of their filters and membranes?

To optimize filtration systems and make the most out of filters and membranes, several strategies can be adopted:

Effective pretreatment

Well designed and operated pre-treatment is essential for the downstream biological or membrane filtration. This helps in removing potential foulants in pre-treatment itself, which further enhances the health of the biological reactors and the tertiary treatment process in a wastewater treatment plant.

To maximize efficiency and longevity in water treatment systems, the following pre-treatment strategies are critical:

• Effective coagulation & flocculation.
• Granular media filtration/Micronic cartridge filter before RO.
• Sedimentation and floatation.
• Ultrafiltration.
• Appropriate antiscalant dosing, biocides & dispersant.

System design optimization

Membrane Selection: Choosing the appropriate membrane type and pore size depending on the type of wastewater to be treated is crucial for optimizing the system’s performance.

Selecting the right system design configuration: Consider, for example, a high crossflow system. In this configuration the feedwater is pumped across the membrane at a higher velocity, which helps to create shear forces that prevent particles from sticking to the membrane surface. This reduces the build-up of fouling layers and extends the operational life of the membrane.

Selecting the right filter for specific contaminants, optimizing filtration velocities, flow rates, and pressure requirements, and designing systems with smooth surfaces to maintain constant flow rates and reduce adhesion points for foulants are all important considerations.

Advanced technologies

Nanotechnology: New nanofiltration membranes offer higher permeability and selectivity, allowing for more efficient filtration of smaller particles and contaminants.

Hybrid systems: Combining different types of membranes, such as microfiltration and nanofiltration, can handle a wider range of contaminants and improve overall water quality.

Pulse Flow RO: Pulse Flow Reverse Osmosis technology (PFRO) is a single-stage process that periodically discharges the brine flow in short, high-velocity bursts. This pulse flow process, featuring shorter cycles than the induction time, achieves high supersaturation of dissolved minerals, thus preventing crystal formation.

Operational strategies

Proper Maintenance: Regular cleaning and maintenance of the system can prevent fouling and reduce energy consumption.

Monitoring and Control: Continuously monitoring and controlling parameters such as flow rate, SDI, pressure, and pH to minimize fouling risk and optimize energy efficiency. Avoid overloading of membranes by controlling the recovery rate. Implement online monitoring tools (RO normalisation software) to detect fouling.

Cleaning Optimization: Developing effective cleaning strategies, such as using a combination of alkaline and acidic solutions, can fully recover membrane flux without damaging other properties.

Advanced monitoring techniques

Implementing real-time fouling detection and characterization methods is key. Understanding the science behind membrane fouling is crucial for developing more efficient and cost-effective filtration systems. By addressing the root causes and mechanisms of fouling, researchers and engineers can design better membranes, optimize operational conditions, and implement more effective fouling control strategies.

Plant historical data analysis

Analyzing flow, TSS, pH, salinity, pressure, temperature, and other historical data can be useful to alert the real plant situation and membrane behavior before major fouling occurrences and help to avoid breakdowns in the plant.

Cleaning protocols

Develop effective chemical and physical cleaning methods to remove foulants, and conduct periodic chemical cleaning and maintenance to remove deposits before they become severe. Use specific cleaning agents tailored to the type of fouling (e.g., acid cleaning for scaling and alkali for organic).

Environmental implications of fouling

Fouling in filtration systems, while primarily a technical challenge, also poses significant environmental concerns. The accumulation of biofouling, chemical precipitates, and organic compounds not only reduces the efficiency of filtration systems but can lead to increased chemical usage, higher energy consumption, and the potential discharge of harmful substances into ecosystems. Effective fouling management is therefore not just about maintaining operational efficiency but also about enhancing the sustainability of industrial processes.

Harnessing the science of fouling for optimal system performance

Understanding the science behind fouling of filters and membranes is essential for optimizing the efficiency and longevity of filtration systems.

By recognizing the various forms of fouling: physical, organic, biofouling, and chemical, wastewater professionals can implement strategic prevention and maintenance techniques, so operations can enhance performance and mitigate the common issues associated with fouling.

This knowledge empowers engineers and technicians to design more robust systems, select appropriate preventive measures, and apply targeted cleaning protocols, ultimately leading to more sustainable and cost-effective operations in industries relying heavily on filtration technologies.
