Porous crystals extract pharmaceutical pollutants from wastewater effluent

Researchers have developed porous crystals made from pomegranate extract to capture and degrade pharmaceutical molecules found in local municipal wastewater, according to a press release from Stockholm University.

Wastewater treatment plants are facing the challenge of removing emerging organic contaminants (EOCs) such as active pharmaceutical ingredients, requiring new materials and technologies.

One strategy for removing pollutants from water is by using porous materials that behave like sponges. Metal-organic frameworks (MOFs) are a type of nanoporous material that are made of metal ions and organic molecules. Most MOFs are made using synthetic organic molecules.

But now researchers from Stockholm University’s Department of Materials and Environmental Chemistry, have managed to develop new porous MOFs using a naturally occurring molecule found in plants: ellagic acid.

“Ellagic acid is one of the main building units of naturally occurring polyphenols known as tannins, which are common in fruits, berries, nuts, and tree bark,” said Erik Svensson Grape, PhD student at the Department of Materials and Environmental Chemistry. “By combining ellagic acid, which was extracted from either pomegranate peel or tree bark, with zirconium ions, we developed a new highly porous MOF which we named SU-102.”

The research is published in the scientific journal Nature Water.

In order to test the performance of SU-102, water that had already been purified at a local wastewater treatment facility was further treated with the new MOF.

The results showed that SU-102 removed many of the pharmaceutical pollutants that were not fully removed by the wastewater treatment facility. Measuring for 17 pharmaceutical EOCs in the wastewater plant effluent, the framework was particularly capable of adsorbing the nine detected cationic compounds.

In addition to capturing the pharmaceutical pollutants, SU-102 was also used to break down the antibiotic sulphamethazine using photodegradation.

“This has been a very exciting project as we got the opportunity to work directly with water samples from the treatment plant, thereby finding an application where our material could be put to use toward a very pressing environmental issue,” said Grape. “We hope one day that SU-102 will be used on a bigger scale and also for other environmental applications.”
